Descripción
The HRV-W PLUS water meter is characterized by its high measurement accuracy. Pressure loss due to measurement effects is minimal.
This meter uses an axial turbine as a speed sensor. The turbine shaft coincides with the water flow axis. It features a magnetic drive and a dry dial. The turbine’s special design allows for high sensitivity at low flow rates.
The measuring insert is encapsulated and rotatable. The internal display does not fog up, ensuring easy reading.
Technical features:
- Pre-installed for pulse transmitter.
- Dry clockwork, 360° adjustable.
- Direct magnetic drive.
- U0/D0 metrology.
- IP68 protection.
- Pressure loss class ΔP16.
Notable features:
- GGG cast iron body.
- A2-70 stainless steel screws.
- Baked epoxy paint suitable for drinking water.
- Stainless steel + technical plastic mechanism.
- Fully removable mechanism without having to disassemble it from the pipe.
- Horizontal and vertical installation possible.
- Transmitter cable installation without the need for sealing.
*MID 2014/32/EU certified.
