Descripción
Basic opening and closing operation due to the pressure exerted by the water in the pipeline. The valve is suitable for:
Air venting during system start-up, while the pipes are being filled
Air inlet during system shutdown, while the pipes are being drained
Releasing small pockets of pressurized air during system operation.
Available for POTABLE WATER
SPECIFICATIONS
Materials
Body: Polyamide with fiberglass
Base: Polyamide with fiberglass or brass
Sealing gasket: NBR
Float: Polypropylene
Reed: EPDM or silicone
Maximum working pressure:
– 10 bar (plastic)
– 16 bar (brass)
